| Model | 10KVA | 15KVA | 20KVA |
| Input Power | 220VAC (Standard) |
| Range of Input Voltage | Model 220V:154-264VAC ± 3V (Normal Mode) 185-264 ± 3V (UPS Model) |
| Input frequency | 50/60Hz±5% |
| Output Rated Power | 8000W | 12000W | 16000W |
| AC Output Voltage | The output voltage under AC is the same as the input voltage |
| AC output frequency | The output voltage frequency under AC is the same as the input
frequency |
| Output Voltage under INV Mode | 220VAC±10% |
| Output frequency under INV mode | 50/60HZ±1% |
| Output Waveform under INV Mode | Pure Sine Wave |
| Battery type | External lead acid battery or water battery |
| Battery voltage | 96VDC / 192VDC | 96VDC / 192VDC | 192VDC |
| Battery Charging Voltage | 108DC / 216VDC | 108DC / 216VDC | 216VDC |
| Maximum AC Charging Current | 24A / 15A | 35A / 22A | 30A |
| Range of Battery Charging Voltage | 154-264VAC±3V |
| Transfer Time | ≤10ms(UPS mode)/≤20ms (INV mode) |
| Load peak ratio | (MAX)3:1 |
| Static power(W) | 120W | 250W | |
| Protection function | Input overcurrent air switch protection under AC mode |
| overload protection, short circuit protection, low voltage
protection, (battery reverse connection insurance) under INV mode |
| Status display | Dot matrix fine screen plus LED display |
| Through the page key, can view the AC voltage, AC frequency, PV
voltage, PV current, output voltage, output frequency, battery
voltage, load current and other parameters. |
| LED display mains, charging status, inverter status, fault status |
| Audible alarm | Low battery protection-continuous beeping |
| Low battery protection-1 second beeping |
| Overload-continuous beeping |
| Overload less than 130%-1 second beeping and shutdown the output
after 30 seconds; Overload more than 150%,shutdown the output after
300ms |
| Malfunction-continuous beeping |
| Working temperature | 0℃~40℃ |
| Storage temperature | —15℃~45℃ |
| Relative humidity | —10℃~90℃Non condensing |
| Accoustic Noise(db) | <45dB |
| Dimension(L*W*H)mm | 570*300*680 |
| Packing Dimension(L*W*H)mm | 620*376*850 |
| N.W (KG) | 69 | 89 | 99 |
