Prismatic Lithium Iron Phosphate Battery , 12V 300AH Lifepo4 Battery

Ask Lasest Price
Brand Name :	LEEHO
Model Number :	LI12-300AH
Certification :	CE,MSDS
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Add to Cart

Product Details
Company Profile

Prismatic Lithium Iron Phosphate Battery , 12V 300AH Lifepo4 Battery

12v 300AH lithium iron phosphate prismatic cells li phosphate battery recharge lithium ion battery 12 volt lithium batte

Product Paramenters

Electrical Characteristics	Nominal Voltage	12.8V
	Nominal capacity	300Ah
	Energy	3840Wh
	Internal Resistance	≤60mΩ
	Cycle life	≥4000 cycles @1C 100%DOD
	Months Self Discharge	<3%
	Efficiency of Charge	100% @0.5C
	Efficiency of Discharge	96~99% @1C
	Charge cut-off Voltage	14.6±0.2V
	Charge Mode	0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV)
Standard Charge	Standard Charge Current	90A
	Max. Charge Current	100A
	Charge ending current	10A
	Standard discharge Current	90A
	Max. Continuous discharge Current	150A
Standard Discharge	Discharge Cut-off Voltage	9.5v
	Charge Temperature	0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity
	Discharge Temperature	-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity
Environmental	Storage Temperature	0℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity
	Water Dust Resistance	IP65
Mechanical	Plastic Case	ABS
	Dimensions (mm)	Customizable
	Weight	26kg
	Terminal	M8
Color		Black,customizable

Feature

2/3 Lighter & Lasts up to 10x longer than a standard SLA battery!!
Full Sealed,can be used anyway around as it is non spillable.
Can be simply drop in as a direct replacement for the traditional lead acid battery.
The Battery pack is supplied fully protected by a specially designed lithium BMS that constantly monitors every cell to ensure the battery is always optimized for best performance and life.

LiFePO4 Battery series- for RV/Marine/Solar/Golf cart

Model No.	Voltage	Capacity	Dimension	Weight
LH-1260E	12V	60Ah	L260W167H210mm	7kg
LH-1270E	12V	70Ah	L260W167H210mm	8kg
LH-1280E	12V	80Ah	L260W167H210mm	9kg
LH-12100E	12V	100Ah	L330W174H220mm	11kg
LH-12120E	12V	120Ah	L406W173H236mm	13kg
LH-12120E	12V	120Ah	L330W174H220mm	13kg
LH-12150E	12V	150Ah	L406W173H236mm	15kg
LH-12150E	12V	150Ah	L330W174H220mm	15kg
LH-12200E	12V	200Ah	L406W173H236mm	18kg
LH-12250E	12V	250Ah	L520W268H230mm	22kg
LH-12300E	12V	300Ah	L520W268H220mm	30kg
LH-12400E	12V	400Ah	L520W268H220mm	39kg
LH-2450E	24V	50Ah	L330W174H220mm	11kg
LH-2460E	24V	60Ah	L330W174H220mm	12kg
LH-24100E	24V	100Ah	L520W268H230mm	18kg
LH-24150E	24V	150Ah	L520W268H220mm
LH-24200E	24V	200Ah	L520W268H220mm	39kg
LH-4850E	48V	50Ah	L520W268H230mm	18kg
LH-48100E	48V	100Ah	L520W268H220mm	39kg

Packing & Delivery

Packing

Our Normal Packing:1)SLA replacement batteries and light weight batteries,are usually
packed in single carton(per piece in 1 carton), protected by foam
from top and button.
2)For heavy high voltage/high capacity batteries,are usualy packed
with wooden frame for safe delivery.
OEM packing:
Since we're direct factory,we also support package
customzition.While reach the OEM QTY,we can design and make
according to your requirements.

Delivery

1) Sample orderNormally,the samples will be delivered by
express(DHL,Fedex,TNT,UPS) or Air depending on different products.
Large scale batteries will be probably delivered by ship.
2) Mass orderAir,Ship for selection,will deliver according to clients' decision.
3) We have got UN38.3,MSDS and other shipping port certificate.
