Name: Ja Mono Perc Half Cut Bifacial Solar Panel B Grade
Brand: LEEHO
Price: 1 USD

Ask Lasest Price
Brand Name :	LEEHO
Model Number :	JAM72D30
Certification :	IEC61215/IEC61730/TUV/CQC/ISO
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	30000PC
Delivery Time :	5-8working days

Add to Cart

Ja Brand B Grade Bicfacial 535w Stock Mono Perc

Features:

TYPE	JAM72D30 -525/MB	JAM72D30 -530/M B	JAM72D30 -535/MB	JAM72D30 -540/M B	JAM72D30 -545/MB	JAM72D30 -550/MB
Rated Maximum Power(Pmax) [W]	525	530	535	540	545	550
Open Circuit Voltage(Voc) [V]	49.15	49.3	49.45	49.6	49.75	49.9
Maximum Power Voltage(Vmp) [V]	41.15	41.31	41.47	41.64	41.8	41.96
Short Circuit Current(lsc) [A]	13.65	13.72	13.79	13.86	13.93	14
Maximum Power Current(lnnp) [A]	12.76	12.83	12.9	12.97	13.04	13.11
Module Efficiency [%]	20.3	20.5	20.6	20.8	21	21.2
Power Tolerance	0-+5W
Temperature Coefficient of lsc(a_lsc)	+0.045%/°C
Temperature Coefficient of Vbc(3_Voc)	-0.275%/°C
Temperature Coefficient of Pmax(Y_Pmp)	-0.350%/°C
STC	Irradiance 1000W/m2, cell temperature 25°C, AM1.5G

ELECTRICAL CHARACTERISTICS WITH DIFFERENT POWER RANGES (REFRENCE TO 10% SOLAR ILLUMINANCE RATIO)							OPERATING CONDITIONS
TYPE	JAM72D30 -525/MB	JAM72D30 -530/M B	JAM72D30 -535/MB	JAM72D30 -540/M B	JAM72D30 -545/MB	JAM72D30 -550/MB	Maximum System Voltage	1500V DC
Rated Max Power(Pmax) [W]	562	567	572	578	583	589	Operating Temperature	-40°C~+85°C
Open Circuit Voltage(Voc) [V]	49.54	49.67	49.80	49.93	50.03	50.21	Maximum Series Fuse Rating	30A
Max Power Voltage(Vmp) [V]	41.53	41.77	41.99	42.24	42.43	42.67	Maximum Static Load,Front* Maximum Static Load,Back*	5400Pa(112lb/ft2) 2400Pa(50 lb/ft2)
Short Circuit Current(lsc) [A]	14.34	14.39	14.45	14.50	14.56	14.63	NOCT	45±2°C
Max Power Current(lmp) [A]	13.52	13.58	13.63	13.69	13.74	13.79	Bifacial ity**	70%±10%
Bifaciality=Pmax,rear/Rated Pmax,front							Fire Performance	UL Type 29

We have the stock solar panel of top 10 tire 1 factories all the year round.

If you interested,please leave contact information. we will send it to you news!

Ja Mono Perc Half Cut Bifacial Solar Panel B Grade
